Open WebUI 集成企业微信认证开发文档

1. 系统架构

1.1 技术栈

• 前端: Vue3 + TypeScript
• 后端: FastAPI
• 数据库: PostgreSQL
• 缓存: Redis
• 认证: 企业微信 OAuth2.0

  1.2 系统模块

  2. 数据库设计

  -- 用户表
  CREATE TABLE users (
      id SERIAL PRIMARY KEY,
      wecom_userid VARCHAR(64) UNIQUE NOT NULL,
      name VARCHAR(100) NOT NULL,
      avatar_url TEXT,
      department JSON,
      created_at TIMESTAMP WITH TIME ZONE DEFAULT CURRENT_TIMESTAMP,
      last_login_at TIMESTAMP WITH TIME ZONE
  );
  -- 会话表
  CREATE TABLE chat_sessions (
      id SERIAL PRIMARY KEY,
      user_id INTEGER REFERENCES users(id),
      title VARCHAR(200),
      model VARCHAR(50),
      created_at TIMESTAMP WITH TIME ZONE DEFAULT CURRENT_TIMESTAMP,
      updated_at TIMESTAMP WITH TIME ZONE DEFAULT CURRENT_TIMESTAMP
  );
  -- 消息表
  CREATE TABLE messages (
      id SERIAL PRIMARY KEY,
      session_id INTEGER REFERENCES chat_sessions(id),
      role VARCHAR(20) CHECK (role IN ('user', 'assistant', 'system')),
      content TEXT,
      created_at TIMESTAMP WITH TIME ZONE DEFAULT CURRENT_TIMESTAMP
  );


  3. 后端实现

  3.1 配置文件

  from pydantic_settings import BaseSettings
  class Settings(BaseSettings):
      # 数据库配置
      DATABASE_URL: str = "postgresql://user:password@localhost:5432/openwebui"

      # Redis配置
      REDIS_URL: str = "redis://localhost:6379"

      # 企业微信配置
      WECOM_CORPID: str
      WECOM_CORPSECRET: str
      WECOM_AGENT_ID: int
      WECOM_REDIRECT_URI: str

      # JWT配置
      JWT_SECRET_KEY: str
      JWT_ALGORITHM: str = "HS256"
      ACCESS_TOKEN_EXPIRE_MINUTES: int = 60 * 24
      class Config:
          env_file = ".env"


  3.2 认证服务

  from fastapi import HTTPException
  import httpx
  from typing import Dict
  class WecomAuthService:
      def __init__(self, settings):
          self.settings = settings
          self.access_token = None

      async def get_access_token(self) -> str:
          async with httpx.AsyncClient() as client:
              response = await client.get(
                  "https://qyapi.weixin.qq.com/cgi-bin/gettoken",
                  params={
                      "corpid": self.settings.WECOM_CORPID,
                      "corpsecret": self.settings.WECOM_CORPSECRET
                  }
              )
              data = response.json()
              if data.get("errcode") != 0:
                  raise HTTPException(status_code=401, detail="获取access_token失败")
              return data["access_token"]

      async def get_user_info(self, code: str) -> Dict:
          token = await self.get_access_token()
          async with httpx.AsyncClient() as client:
              response = await client.get(
                  "https://qyapi.weixin.qq.com/cgi-bin/user/getuserinfo",
                  params={
                      "access_token": token,
                      "code": code
                  }
              )
              return response.json()


  3.3 数据模型

  from sqlalchemy import Column, Integer, String, DateTime
  from sqlalchemy.sql import func
  from .database import Base
  class User(Base):
      __tablename__ = "users"

      id = Column(Integer, primary_key=True, index=True)
      wecom_userid = Column(String, unique=True, index=True)
      name = Column(String)
      avatar_url = Column(String)
      created_at = Column(DateTime(timezone=True), server_default=func.now())
      last_login_at = Column(DateTime(timezone=True), onupdate=func.now())


  4. 前端实现

  4.1 登录组件




        企业微信登录




  import { useAuth } from '@/composables/useAuth'
  const { loginWithWecom } = useAuth()
  const handleLogin = () => {
    const redirect_uri = encodeURIComponent(window.location.origin + '/auth/callback')
    const url = `https://open.work.weixin.qq.com/wwopen/sso/qrConnect?appid=${import.meta.env.VITE_WECOM_CORPID}&agentid=${import.meta.env.VITE_WECOM_AGENT_ID}&redirect_uri=${redirect_uri}`
    window.location.href = url
  }



  4.2 用户状态管理

  import { defineStore } from 'pinia'
  export const useAuthStore = defineStore('auth', {
    state: () => ({
      user: null,
      token: null,
    }),

    actions: {
      async login(code: string) {
        try {
          const response = await fetch('/api/auth/wecom/login', {
            method: 'POST',
            headers: {
              'Content-Type': 'application/json',
            },
            body: JSON.stringify({ code }),
          })
          const data = await response.json()
          this.token = data.token
          this.user = data.user
          localStorage.setItem('token', data.token)
        } catch (error) {
          console.error('登录失败:', error)
          throw error
        }
      },
    },
  })


  5. 部署说明

  5.1 环境要求

  • Python 3.8+
  • Node.js 16+
  • PostgreSQL 13+
  • Redis 6+

    5.2 安装步骤

    1. 克隆项目并安装依赖

    git clone https://github.com/open-webui/open-webui.git
    cd open-webui
    # 后端依赖
    cd backend
    pip install -r requirements.txt
    # 前端依赖
    cd ../frontend
    npm install


    1. 配置环境变量

    DATABASE_URL=postgresql://user:password@localhost:5432/openwebui
    REDIS_URL=redis://localhost:6379
    WECOM_CORPID=your_corpid
    WECOM_CORPSECRET=your_secret
    WECOM_AGENT_ID=your_agent_id
    JWT_SECRET_KEY=your_secret_key


    1. 初始化数据库

    cd backend
    alembic upgrade head


    1. 启动服务

    # 后端服务
    uvicorn main:app --host 0.0.0.0 --port 8000
    # 前端服务
    cd ../frontend
    npm run dev


    6. 测试计划

    6.1 单元测试

    import pytest
    from services.auth import WecomAuthService
    async def test_wecom_auth():
        service = WecomAuthService(settings)
        token = await service.get_access_token()
        assert token is not None


    6.2 集成测试检查清单

    • 企业微信扫码登录流程
    • 用户信息同步
    • 会话持久化
    • Token 过期处理
    • 并发会话管理

      7. 安全考虑

      1. 所有API请求需要JWT认证
      2. 使用HTTPS进行传输加密
      3. 实现请求频率限制
      4. 定期清理过期会话
      5. 敏感信息加密存储

      8. 维护建议

      1. 定期备份数据库
      2. 监控系统资源使用
      3. 记录详细的操作日志
      4. 定期更新依赖包
      5. 制定故障恢复方案
