Flutter——最详细原生交互（MethodChannel、EventChannel、BasicMessageChannel）使用教程

1. MethodChannel（方法通道）

   用途：实现 双向通信，用于调用原生平台提供的 API 并获取返回结果。

   场景：适合一次性操作，如调用相机、获取设备信息等。

使用步骤：

• Flutter 端：通过 MethodChannel监听事件流。

    static const platform =
        MethodChannel('com.example.fltest.plugin.DeviceInfoPlugin');


  • Android 端（Kotlin）

        private var methodChannel: MethodChannel? = null
      val CHANNEL: String = "com.example.fltest.plugin.DeviceInfoPlugin"

      private fun getPhoneNumber(): Any? {
            val telephonyManager = context.getSystemService(Context.TELEPHONY_SERVICE) as TelephonyManager?
    //        val phoneNumber = telephonyManager!!.line1Number
            val phoneNumber = "18627000332"
            return phoneNumber
        }


    1. EventChannel（事件通道）

       用途：实现 单向数据流，用于原生平台向 Flutter 持续发送事件（如传感器数据）。

       场景：适合实时数据流，如监听陀螺仪、GPS 位置更新等。

       使用步骤：

    • Flutter 端：通过 EventChannel 监听事件流。

      static const eventChannel =
            EventChannel('com.example.fltest.plugin.DeviceInfoPlugin/event');
        Stream get _batteryLevelStream {
          return eventChannel.receiveBroadcastStream("111").cast();
        }


      • Android 端（Kotlin）


        class DeviceInfoPlugin(var context: Context) : EventChannel.StreamHandler, FlutterPlugin {
            private var eventChannel: EventChannel? = null
            val EVENT_CHANNEL: String = "com.example.fltest.plugin.DeviceInfoPlugin/event"
            override fun onMethodCall(call: MethodCall, result: MethodChannel.Result) {
                    result.notImplemented()
            }
            override fun onAttachedToEngine(binding: FlutterPlugin.FlutterPluginBinding) {
                setupChannels(binding.binaryMessenger, binding.applicationContext)
            }
            override fun onDetachedFromEngine(binding: FlutterPlugin.FlutterPluginBinding) {
                teardownChannels()
            }
            private fun setupChannels(messenger: BinaryMessenger, context: Context) {
                this.context = context
                eventChannel = EventChannel(messenger, EVENT_CHANNEL)
                eventChannel?.setStreamHandler(this)
            }
            private fun teardownChannels() {
                eventChannel?.setStreamHandler(null)
                eventChannel = null
            }
            private val mainHandler = Handler(Looper.getMainLooper())
            override fun onListen(arguments: Any?, events: EventChannel.EventSink?) {
                Toast.makeText(context, arguments.toString(), Toast.LENGTH_SHORT).show()
                events?.let {
                    sendBatteryLevel(it)
                    events.success(1)
                    mainHandler.postDelayed({
                        events.success(2)
                    }, 2000)
                    mainHandler.postDelayed({ events.success(3) }, 4000)
                }
            }
            override fun onCancel(arguments: Any?) {
            }
            private fun sendBatteryLevel(events: EventChannel.EventSink) {
                val batteryLevel = -1
                if (batteryLevel != -1) {
                    events.success(batteryLevel)
                } else {
                    events.error("UNAVAILABLE", "Battery level not available.", null);
                }
            }
        }


        1. BasicMessageChannel（基础消息通道）

           用途：支持 异步消息传递，使用自定义编解码器传递数据。

           场景：适合简单的数据交换（如 JSON、二进制数据）。

        使用步骤：

        • Flutter 端：通过 BasicMessageChannel监听事件流。

            final BasicMessageChannel messageChannel =
                BasicMessageChannel(
              'com.example.fltest.plugin.DeviceInfoPlugin/basicMessage',
              StringCodec(),
            );

          // 发送消息
          Future sendMessage(String message) async {
            return await messageChannel.send(message);
          }
              @override
            void initState() {
              super.initState();
              // 设置消息处理器
              messageChannel.setMessageHandler((String? message) async {
                print('Received message from native: $message');
                return '$message';
              });
            }



          • Android 端（Kotlin）

            package com.example.fltest.plugin
            import android.content.Context
            import android.os.Handler
            import android.os.Looper
            import android.telephony.TelephonyManager
            import android.widget.Toast
            import io.flutter.embedding.engine.plugins.FlutterPlugin
            import io.flutter.plugin.common.BasicMessageChannel
            import io.flutter.plugin.common.BasicMessageChannel.Reply
            import io.flutter.plugin.common.BinaryMessenger
            import io.flutter.plugin.common.EventChannel
            import io.flutter.plugin.common.MethodCall
            import io.flutter.plugin.common.MethodChannel
            import io.flutter.plugin.common.MethodChannel.MethodCallHandler
            import io.flutter.plugin.common.StandardMessageCodec
            import io.flutter.plugin.common.StringCodec
            class DeviceInfoPlugin(var context: Context) :  FlutterPlugin {
                private var basicMessageChannel: BasicMessageChannel? = null
                val BASIC_MESSAGE_CHANNEL: String = "com.example.fltest.plugin.DeviceInfoPlugin/basicMessage"
                override fun onMethodCall(call: MethodCall, result: MethodChannel.Result) {

                        result.notImplemented()

                }
                override fun onAttachedToEngine(binding: FlutterPlugin.FlutterPluginBinding) {
                    setupChannels(binding.binaryMessenger, binding.applicationContext)
                }
                override fun onDetachedFromEngine(binding: FlutterPlugin.FlutterPluginBinding) {
                    teardownChannels()
                }
                private fun setupChannels(messenger: BinaryMessenger, context: Context) {
                    this.context = context
                    basicMessageChannel = BasicMessageChannel(messenger, BASIC_MESSAGE_CHANNEL, StringCodec.INSTANCE)
                    basicMessageChannel?.setMessageHandler { message, reply ->
                        println("Received message from Flutter: $message")
                        reply.reply("Message received")
                        basicMessageChannel?.send(message
                        ) { reply -> Toast.makeText(context, reply.toString(), Toast.LENGTH_SHORT).show() }
                    }
                    // 发送消息
            basicMessageChannel.send("Hello from Android") { reply ->
                Log.d("TAG", "Reply: $reply")
            }
                }
                private fun teardownChannels() {

                }

                override fun onCancel(arguments: Any?) {
                }
            }


            在MainActivity初始化添加插件类

            package com.example.fltest
            import com.example.fltest.plugin.DeviceInfoPlugin
            import io.flutter.embedding.android.FlutterActivity
            import io.flutter.embedding.engine.FlutterEngine
            class MainActivity: FlutterActivity(){
                override fun configureFlutterEngine(flutterEngine: FlutterEngine) {
                    super.configureFlutterEngine(flutterEngine)
                    flutterEngine.plugins.add(DeviceInfoPlugin(this))
                }
            }


            总结：

            方法	方向	使用场景
            MethodChannel	双向	调用原生 API 并获取结果
            EventChannel	单向（原生→Flutter）	监听持续事件（如传感器）
            BasicMessageChannel	双向	简单消息传递（字符串、二进制数据）

            根据具体需求选择合适的方式，可覆盖绝大多数跨平台交互场景。
