PostgreSQL 向量扩展插件pgvector安装和使用

安装postgresql
pgvector下载和安装
安装错误调试

错误调试1

尝试解决 AP1 ：启动postgresql
错误调试2

尝试解决 AP2 : 使用apt-get install postgresql-server
错误调试3

尝试解决 AP3 ：卸载apt-get 安装
错误调试4

设置环境变量PG_CONFIG
编译成功
使用pgvector

测试例
列出当前数据库中已安装的扩展（extensions）

参考

PostgreSQL 向量扩展插件pgvector安装和使用

pgvector 是一个 PostgreSQL 扩展，能够让PostgreSQL 提供向量（vector）数据类型和相关操作功能。

参考：

https://github.com/pgvector/pgvector

安装postgresql

利用pgvector 前提是事先安装好postgresql，安装postgresql例可参考下文。

参考：

Linux（Ubuntu）源码安装postgresql16.3

https://editor.csdn.net/md/articleId=142500497

pgvector下载和安装

安装命令如下：

cd
git clone --branch v0.7.4 https://github.com/pgvector/pgvector.git
cd pgvector
make
make install # may need sudo

参考：

https://github.com/pgvector/pgvector

例：下载

root@autodl-container-616f40a3b3-41cb82d9:~#  su - postgres
postgres@autodl-container-616f40a3b3-41cb82d9:~$ pwd
/var/lib/postgresql
postgres@autodl-container-616f40a3b3-41cb82d9:~$ ls
10  pgsql16  postgresql-16.3  postgresql-16.3.tar.gz
postgres@autodl-container-616f40a3b3-41cb82d9:~$ git clone --branch v0.7.4 https://github.com/pgvector/pgvector.git
Cloning into 'pgvector'...
remote: Enumerating objects: 10650, done.
remote: Counting objects: 100% (4165/4165), done.
remote: Compressing objects: 100% (954/954), done.
remote: Total 10650 (delta 3388), reused 3493 (delta 3193), pack-reused 6485 (from 1)
Receiving objects: 100% (10650/10650), 1.60 MiB | 544.00 KiB/s, done.
Resolving deltas: 100% (7952/7952), done.
Note: checking out '103ac50f1a90b47a72003e8e8628a55ec372f202'.
You are in 'detached HEAD' state. You can look around, make experimental
changes and commit them, and you can discard any commits you make in this
state without impacting any branches by performing another checkout.
If you want to create a new branch to retain commits you create, you may
do so (now or later) by using -b with the checkout command again. Example:
  git checkout -b
postgres@autodl-container-616f40a3b3-41cb82d9:~$

安装错误调试

错误调试1

尝试编译和安装

例：

postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ make
You need to install postgresql-server-dev-X.Y for building a server-side extension or libpq-dev for building a client-side application.
cp sql/vector.sql sql/vector--0.7.4.sql

编译时候汇报如上错误可能是由于postgresql没有启动。

postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ psql
psql: error: connection to server on socket "/tmp/.s.PGSQL.5432" failed: Connection refused
        Is the server running locally and accepting connections on that socket?
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$
postgres@autodl-container-616f40a3b3-41cb82d9:~$ ps -xf|grep postgres
  1504 pts/3    S+     0:00  _ grep postgres
postgres@autodl-container-616f40a3b3-41cb82d9:~$ pg_ctl -D /var/lib/postgresql/pgsql16/data status
pg_ctl: no server running

尝试解决 AP1 ：启动postgresql

postgres@autodl-container-616f40a3b3-41cb82d9:~$ pg_ctl -D /var/lib/postgresql/pgsql16/data -l logfile start
pg_ctl: another server might be running; trying to start server anyway
waiting for server to start.... done
server started
postgres@autodl-container-616f40a3b3-41cb82d9:~$  ps -xf|grep postgres
  1197 pts/0    S+     0:00  _ grep postgres
  1188 ?        Ss     0:00 /var/lib/postgresql/pgsql16/bin/postgres -D /var/lib/postgresql/pgsql16/data
  1189 ?        Ss     0:00  _ postgres: checkpointer
  1190 ?        Ss     0:00  _ postgres: background writer
  1192 ?        Ss     0:00  _ postgres: walwriter
  1193 ?        Ss     0:00  _ postgres: autovacuum launcher
  1194 ?        Ss     0:00  _ postgres: logical replication launcher
postgres@autodl-container-616f40a3b3-41cb82d9:~$  psql
psql (16.3)
Type "help" for help.
postgres=# help
You are using psql, the command-line interface to PostgreSQL.
Type:  copyright for distribution terms
       h for help with SQL commands
       ? for help with psql commands
       g or terminate with semicolon to execute query
       q to quit
postgres=#

错误调试2

再次编译，出错。

（图片来源网络，侵删）

postgres@autodl-container-616f40a3b3-41cb82d9:~$ pwd
/var/lib/postgresql
postgres@autodl-container-616f40a3b3-41cb82d9:~$ cd pgvector
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ make
You need to install postgresql-server-dev-X.Y for building a server-side extension or libpq-dev for building a client-side application.
make: Nothing to be done for 'all'.
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ postgres --version
postgres (PostgreSQL) 16.3
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ psql --version
psql (PostgreSQL) 16.3

无法识别postgresql-server-dev-X.Y 。

尝试解决 AP2 : 使用apt-get install postgresql-server

postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ apt-get install postgresql-server*
E: Could not open lock file /var/lib/dpkg/lock-frontend - open (13: Permission denied)
E: Unable to acquire the dpkg frontend lock (/var/lib/dpkg/lock-frontend), are you root?
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ exit
logout
root@autodl-container-616f40a3b3-41cb82d9:~# apt-get install postgresql-server*
Reading package lists... Done
Building dependency tree
Reading state information... Done
Note, selecting 'postgresql-server-dev-all' for glob 'postgresql-server*'
Note, selecting 'postgresql-server' for glob 'postgresql-server*'
Note, selecting 'postgresql-server-dev-10' for glob 'postgresql-server*'
The following additional packages will be installed:
  dctrl-tools iproute2 libatm1 libmnl0 libpq-dev libxtables12
Suggested packages:
  debtags iproute2-doc postgresql-doc-10
The following NEW packages will be installed:
  dctrl-tools iproute2 libatm1 libmnl0 libpq-dev libxtables12 postgresql-server-dev-10 postgresql-server-dev-all
0 upgraded, 8 newly installed, 0 to remove and 169 not upgraded.
Need to get 1983 kB of archives.
After this operation, 10.9 MB of additional disk space will be used.
Do you want to continue? [Y/n] Y
Get:1 https://repo.huaweicloud.com/ubuntu bionic/main amd64 libmnl0 amd64 1.0.4-2 [12.3 kB]
Get:2 https://repo.huaweicloud.com/ubuntu bionic-updates/main amd64 iproute2 amd64 4.15.0-2ubuntu1.3 [721 kB]
Get:3 https://repo.huaweicloud.com/ubuntu bionic/main amd64 libatm1 amd64 1:2.5.1-2build1 [21.9 kB]
Get:4 https://repo.huaweicloud.com/ubuntu bionic-updates/main amd64 libxtables12 amd64 1.6.1-2ubuntu2.1 [28.1 kB]
Get:5 https://repo.huaweicloud.com/ubuntu bionic/main amd64 dctrl-tools amd64 2.24-2build1 [60.9 kB]
Get:6 https://repo.huaweicloud.com/ubuntu bionic-security/main amd64 libpq-dev amd64 10.23-0ubuntu0.18.04.2 [219 kB]
Get:7 https://repo.huaweicloud.com/ubuntu bionic-security/universe amd64 postgresql-server-dev-10 amd64 10.23-0ubuntu0.18.04.2 [905 kB]
Get:8 https://repo.huaweicloud.com/ubuntu bionic-security/universe amd64 postgresql-server-dev-all all 190ubuntu0.1 [14.1 kB]
Fetched 1983 kB in 1s (3436 kB/s)
debconf: delaying package configuration, since apt-utils is not installed
Selecting previously unselected package libmnl0:amd64.
(Reading database ... 44409 files and directories currently installed.)
Preparing to unpack .../0-libmnl0_1.0.4-2_amd64.deb ...
Unpacking libmnl0:amd64 (1.0.4-2) ...
Selecting previously unselected package iproute2.
Preparing to unpack .../1-iproute2_4.15.0-2ubuntu1.3_amd64.deb ...
Unpacking iproute2 (4.15.0-2ubuntu1.3) ...
Selecting previously unselected package libatm1:amd64.
Preparing to unpack .../2-libatm1_1%3a2.5.1-2build1_amd64.deb ...
Unpacking libatm1:amd64 (1:2.5.1-2build1) ...
Selecting previously unselected package libxtables12:amd64.
Preparing to unpack .../3-libxtables12_1.6.1-2ubuntu2.1_amd64.deb ...
Unpacking libxtables12:amd64 (1.6.1-2ubuntu2.1) ...
Selecting previously unselected package dctrl-tools.
Preparing to unpack .../4-dctrl-tools_2.24-2build1_amd64.deb ...
Unpacking dctrl-tools (2.24-2build1) ...
Selecting previously unselected package libpq-dev.
Preparing to unpack .../5-libpq-dev_10.23-0ubuntu0.18.04.2_amd64.deb ...
Unpacking libpq-dev (10.23-0ubuntu0.18.04.2) ...
Selecting previously unselected package postgresql-server-dev-10.
Preparing to unpack .../6-postgresql-server-dev-10_10.23-0ubuntu0.18.04.2_amd64.deb ...
Unpacking postgresql-server-dev-10 (10.23-0ubuntu0.18.04.2) ...
Selecting previously unselected package postgresql-server-dev-all.
Preparing to unpack .../7-postgresql-server-dev-all_190ubuntu0.1_all.deb ...
Unpacking postgresql-server-dev-all (190ubuntu0.1) ...
Setting up libpq-dev (10.23-0ubuntu0.18.04.2) ...
Setting up dctrl-tools (2.24-2build1) ...
Setting up postgresql-server-dev-10 (10.23-0ubuntu0.18.04.2) ...
Setting up libatm1:amd64 (1:2.5.1-2build1) ...
Setting up libxtables12:amd64 (1.6.1-2ubuntu2.1) ...
Setting up libmnl0:amd64 (1.0.4-2) ...
Setting up iproute2 (4.15.0-2ubuntu1.3) ...
Setting up postgresql-server-dev-all (190ubuntu0.1) ...
Processing triggers for libc-bin (2.27-3ubuntu1.2) ...
root@autodl-container-616f40a3b3-41cb82d9:~#

安装的版本不是最新的版本而是10.23。

（图片来源网络，侵删）

错误调试3

再次编译。

postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ make
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Wendif-labels -Wmissing-format-attribute -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -g -g -O2 -fdebug-prefix-map=/build/postgresql-10-XHR5kl/postgresql-10-10.23=. -fstack-protector-strong -Wformat -Werror=format-security -fno-omit-frame-pointer -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -I. -I./ -I/usr/include/postgresql/10/server -I/usr/include/postgresql/internal  -Wdate-time -D_FORTIFY_SOURCE=2 -D_GNU_SOURCE -I/usr/include/libxml2  -I/usr/include/mit-krb5  -c -o src/bitutils.o src/bitutils.c
In file included from src/bitutils.c:3:0:
src/bitutils.h:8:2: error: #error "Requires PostgreSQL 12+"
 #error "Requires PostgreSQL 12+"
  ^~~~~
src/bitutils.c:5:10: fatal error: port/pg_bitutils.h: No such file or directory
 #include "port/pg_bitutils.h"
          ^~~~~~~~~~~~~~~~~~~~
compilation terminated.
: recipe for target 'src/bitutils.o' failed
make: *** [src/bitutils.o] Error 1
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$

make编译调用的postgresql不是之前安装的 16.3，而是apt-get 安装的10.23版本。

（图片来源网络，侵删）

尝试解决 AP3 ：卸载apt-get 安装

卸载apt-get 安装的10.23版本

参考：

卸载apt-get 安装的PostgreSQL版本

https://blog.csdn.net/lukeUnique/article/details/142610650

错误调试4

再次编译。

root@autodl-container-616f40a3b3-41cb82d9:~# su - postgres
postgres@autodl-container-616f40a3b3-41cb82d9:~$ cd /var/lib/postgresql/pgvector
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ ls
CHANGELOG.md  Dockerfile  LICENSE  META.json  Makefile  Makefile.win  README.md  logfile  sql  src  test  vector.control
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ make
Makefile:48: /usr/lib/postgresql/10/lib/pgxs/src/makefiles/pgxs.mk: No such file or directory
make: *** No rule to make target '/usr/lib/postgresql/10/lib/pgxs/src/makefiles/pgxs.mk'.  Stop.
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$

make编译pgvector时无法识别安装的postgresql。

设置环境变量PG_CONFIG

为了让make命令找到安装的postgresql 16.3版本。

重新修改.bash_profile，配置PG_CONFIG和LD_LIBRARY_PATH，指定安装的postgresql 16.3版本。

例：

$ vi .bash_profile

修改成如下内容。

# .bash_profile

# Get the aliases and functions
if [ -f ~/.bashrc ]; then
        . ~/.bashrc
fi

# User specific environment and startup programs
export PG_HOME=/var/lib/postgresql/pgsql16
export LD_LIBRARY_PATH=$LD_LIBRARY_PATH:/var/lib/postgresql/pgsql16/lib
export PG_CONFIG=/var/lib/postgresql/pgsql16/bin/pg_config
export PGDATA=/var/lib/postgresql/pgsql16/data
PATH=$PATH:$HOME/.local/bin:$HOME/bin:$PG_HOME/bin
alias psql='/var/lib/postgresql/pgsql16/bin/psql'
export PATH

编译成功

根据上面的错误调试过程，我们可以看到在编译时候需要配置PG_CONFIG。

root@autodl-container-616f40a3b3-41cb82d9:~# su - postgres
postgres@autodl-container-616f40a3b3-41cb82d9:~$ ls
logfile  pgsql16  pgvector  postgresql-16.3  postgresql-16.3.tar.gz
postgres@autodl-container-616f40a3b3-41cb82d9:~$ cd pgvector
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ ls
CHANGELOG.md  Dockerfile  LICENSE  META.json  Makefile  Makefile.win  README.md  logfile  sql  src  test  vector.control
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ make
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/bitutils.o src/bitutils.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/bitvec.o src/bitvec.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/halfutils.o src/halfutils.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/halfvec.o src/halfvec.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/hnsw.o src/hnsw.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/hnswbuild.o src/hnswbuild.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/hnswinsert.o src/hnswinsert.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/hnswscan.o src/hnswscan.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/hnswutils.o src/hnswutils.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/hnswvacuum.o src/hnswvacuum.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/ivfbuild.o src/ivfbuild.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/ivfflat.o src/ivfflat.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/ivfinsert.o src/ivfinsert.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/ivfkmeans.o src/ivfkmeans.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/ivfscan.o src/ivfscan.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/ivfutils.o src/ivfutils.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/ivfvacuum.o src/ivfvacuum.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/sparsevec.o src/sparsevec.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -I. -I./ -I/var/lib/postgresql/pgsql16/include/server -I/var/lib/postgresql/pgsql16/include/internal  -D_GNU_SOURCE   -c -o src/vector.o src/vector.c
gcc -Wall -Wmissing-prototypes -Wpointer-arith -Wdeclaration-after-statement -Werror=vla -Wendif-labels -Wmissing-format-attribute -Wimplicit-fallthrough=3 -Wshadow=compatible-local -Wformat-security -fno-strict-aliasing -fwrapv -fexcess-precision=standard -Wno-format-truncation -O2 -march=native -ftree-vectorize -fassociative-math -fno-signed-zeros -fno-trapping-math -fPIC -fvisibility=hidden -shared -o vector.so src/bitutils.o src/bitvec.o src/halfutils.o src/halfvec.o src/hnsw.o src/hnswbuild.o src/hnswinsert.o src/hnswscan.o src/hnswutils.o src/hnswvacuum.o src/ivfbuild.o src/ivfflat.o src/ivfinsert.o src/ivfkmeans.o src/ivfscan.o src/ivfutils.o src/ivfvacuum.o src/sparsevec.o src/vector.o -L/var/lib/postgresql/pgsql16/lib    -Wl,--as-needed -Wl,-rpath,'/var/lib/postgresql/pgsql16/lib',--enable-new-dtags  -fvisibility=hidden
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$

make install

postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$  make install
/bin/mkdir -p '/var/lib/postgresql/pgsql16/lib'
/bin/mkdir -p '/var/lib/postgresql/pgsql16/share/extension'
/bin/mkdir -p '/var/lib/postgresql/pgsql16/share/extension'
/usr/bin/install -c -m 755  vector.so '/var/lib/postgresql/pgsql16/lib/vector.so'
/usr/bin/install -c -m 644 .//vector.control '/var/lib/postgresql/pgsql16/share/extension/'
/usr/bin/install -c -m 644 .//sql/vector--0.5.0--0.5.1.sql .//sql/vector--0.1.3--0.1.4.sql .//sql/vector--0.1.1--0.1.3.sql .//sql/vector--0.4.3--0.4.4.sql .//sql/vector--0.1.7--0.1.8.sql .//sql/vector--0.2.0--0.2.1.sql .//sql/vector--0.1.5--0.1.6.sql .//sql/vector--0.5.1--0.6.0.sql .//sql/vector--0.3.1--0.3.2.sql .//sql/vector--0.1.8--0.2.0.sql .//sql/vector--0.2.6--0.2.7.sql .//sql/vector--0.3.0--0.3.1.sql .//sql/vector--0.4.2--0.4.3.sql .//sql/vector--0.6.2--0.7.0.sql .//sql/vector--0.1.4--0.1.5.sql .//sql/vector--0.2.7--0.3.0.sql .//sql/vector--0.6.0--0.6.1.sql .//sql/vector--0.4.1--0.4.2.sql .//sql/vector--0.7.3--0.7.4.sql .//sql/vector--0.4.0--0.4.1.sql .//sql/vector--0.7.1--0.7.2.sql .//sql/vector--0.1.0--0.1.1.sql .//sql/vector--0.2.3--0.2.4.sql .//sql/vector--0.1.6--0.1.7.sql .//sql/vector--0.3.2--0.4.0.sql .//sql/vector--0.2.5--0.2.6.sql .//sql/vector--0.4.4--0.5.0.sql .//sql/vector--0.2.1--0.2.2.sql .//sql/vector--0.7.2--0.7.3.sql .//sql/vector--0.7.0--0.7.1.sql .//sql/vector--0.2.2--0.2.3.sql .//sql/vector--0.6.1--0.6.2.sql .//sql/vector--0.2.4--0.2.5.sql sql/vector--0.7.4.sql '/var/lib/postgresql/pgsql16/share/extension/'
/bin/mkdir -p '/var/lib/postgresql/pgsql16/include/server/extension/vector/'
/usr/bin/install -c -m 644   .//src/halfvec.h .//src/sparsevec.h .//src/vector.h '/var/lib/postgresql/pgsql16/include/server/extension/vector/'
postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$

pgvector的安装成功。

使用pgvector

使用参考https://github.com/pgvector/pgvector

Getting Started
Enable the extension (do this once in each database where you want to use it)
CREATE EXTENSION vector;
Create a vector column with 3 dimensions
CREATE TABLE items (id bigserial PRIMARY KEY, embedding vector(3));
Insert vectors
INSERT INTO items (embedding) VALUES ('[1,2,3]'), ('[4,5,6]');
Get the nearest neighbors by L2 distance
SELECT * FROM items ORDER BY embedding  '[3,1,2]' LIMIT 5;
Also supports inner product (), cosine distance (), and L1 distance (, added in 0.7.0)
Note:  returns the negative inner product since Postgres only supports ASC order index scans on operators

测试例

postgres@autodl-container-616f40a3b3-41cb82d9:~/pgvector$ psql
psql (16.3)
Type "help" for help.
postgres=# CREATE EXTENSION vector;
CREATE EXTENSION
postgres=# CREATE TABLE items (id bigserial PRIMARY KEY, embedding vector(3));
CREATE TABLE
postgres=# INSERT INTO items (embedding) VALUES ('[1,2,3]'), ('[4,5,6]');
INSERT 0 2
postgres=# SELECT * FROM items ORDER BY embedding  '[3,1,2]' LIMIT 5;
 id | embedding
----+-----------
  1 | [1,2,3]
  2 | [4,5,6]
(2 rows)

列出当前数据库中已安装的扩展（extensions）

postgres=# dx
                             List of installed extensions
  Name   | Version |   Schema   |                     Description
---------+---------+------------+------------------------------------------------------
 plpgsql | 1.0     | pg_catalog | PL/pgSQL procedural language
 vector  | 0.7.4   | public     | vector data type and ivfflat and hnsw access methods
(2 rows)
postgres=#

参考

实战PG vector 构建DBA 个人知识库之二: 向量数据库与 PG vector 介绍

https://pgfans.cn/a/3606

数据库技术核心：向量检索（pgvector）

https://blog.csdn.net/ChaoMing_H/article/details/141257149

PostgreSQL向量数据插件–pgvector安装（附PostgreSQL安装）

https://blog.csdn.net/m0_62627802/article/details/135027327

免责声明：我们致力于保护作者版权，注重分享，被刊用文章因无法核实真实出处，未能及时与作者取得联系，或有版权异议的，请联系管理员，我们会立即处理! 部分文章是来自自研大数据AI进行生成,内容摘自(百度百科,百度知道,头条百科,中国民法典,刑法,牛津词典,新华词典,汉语词典,国家院校,科普平台)等数据,内容仅供学习参考,不准确地方联系删除处理! 图片声明：本站部分配图来自人工智能系统AI生成,觅知网授权图片,PxHere摄影无版权图库和百度，360，搜狗等多加搜索引擎自动关键词搜索配图，如有侵权的图片，请第一时间联系我们。
