华为交换机(S5735S-L24P4S-A1)交换机开启web管理模式

1.开启web配置模式

华为交换机(S5735S-L24P4S-A1)该型号交换机默认不开启web管理模式。需要通过Console口配置模式开启web管理模式，方便使用图形化界面升级操作系统

1.进入配置命令模式

Please Press ENTER.

An initial password is required for the first login via the console.

Set a password and keep it safe. Otherwise you will not be able to login via the console.

Please configure the login password (8-16)

Enter Password:admin@huawei.com(交换机默认密码)

Confirm Password:admin@huawei.com(交换机默认密码)

2.开启HTTPS服务

sys

Enter system view, return user view with Ctrl+Z.(交换机回显信息)

[HUAWEI]http secure-server enable

Info: The HTTP secure server has been already started.(交换机回显信息)

Warning: After configuring the source interface or source address, the listening socket will be created.(交换机回显信息)

[HUAWEI]http server enable

Info: The HTTP server has been already started.(交换机回显信息)

Warning: After configuring the source interface or source address, the listening socket will be created.(交换机回显信息)

3.配置Web用户

[Huawei]aaa

[Huawei-aaa]local-user admin password cipher bjmut.com （local-user后的admin为用户名，cipher后的bjmut.com为密码，登陆时用此账号密码登陆）

info: A new user added (交换机回显信息)

[Huawei-aaa] local-user admin service-type http telnet （以下两行local-user后的admin需输入在上一行配置的用户名）

Info: The cipher password has been changed to an irreversible-cipher password.

Warning: The user access modes include Telnet, FTP, or HTTP, so security risks exist.

Info: After changing the rights (including the password, access type, FTP directory, HTTP directory, and level) of a local user, the rights of users already online do not change. The change takes effect to users who go online after the change. (交换机回显信息)

(local-user xxx service-type 命令需要注意：如果需要用这个账号作为多种登陆方式的用户名，则需要在service-type后加上多种登陆服务，如同时将该账号用于telnet、http和console登陆： local-user huawei service-type http telnet terminal)

[Huawei-aaa]local-user admin privilege level 15 (配置登陆账号的权限级别，15为最高级)

Warning: This operation may affect online users, are you sure to change the user privilege level ?[Y/N] (交换机回显信息)

Error: Please choose 'YES' or 'NO' first before pressing 'Enter'. [Y/N]:y

3.配置管理IP

Web配置完成后，还需要为交换机配置一个管理IP，下面以为vlanif1配置IP为例：

[Huawei]interface vlanif 1

[HUAWEI-Vlanif1]ip address  X.X.X.X  X.X.X.X

说明：X.X.X.X  X.X.X.X vlanif1 为交换机管理地址，根据现场情况设置。

本操作手册暂定地址为192.168.1.253 255.255.255.0

`

4.配置指定HTTP/HTTPS服务器端的源接口

[HUAWEI]http server-source -i Vlanif 1

Warning: The operation will reboot the HTTP server. Continue? [Y/N]:y

Info: Succeeded in setting the source interface of the HTTP server to Vlanif1.(交换机回显信息)

Info: Succeeded in starting the HTTP secure server.(交换机回显信息)

Warning: HTTP is not a secure protocol, and it is recommended to use HTTPS.
